Free Air REVO subs are recommended primarily for Infinite Baffle (Free Air) applications where a dedicated subwoofer enclosure is not available or practical.
Both 10� & 12� REVO FA subs are available in White or Black frames (Black frames use metallic grey cones). All REVO FA Subs are available in either single 2 Ohm or single 4 Ohm impedances.
All REVO 10� & 12� Subwoofers share the same design features:
• Nylas Composite Frame - to withstand extreme environmental use. Designed to accept optional RGB wiring.
• Injection Molded Composite Cone – For durability & low distortion.
• Santoprene Rubber Spider – Much more durable to water & temperature changes than a traditional treated Cotton Spider used by the majority of marine speakers & subwoofers.
• Santoprene Rubber Surround – Offers a superior bond to the composite cone.Also resists deterioration due to water, temperature & ultraviolet exposure.
• Stainless Steel Terminals – Designed to resist corrosion.
All REVO Subwoofers are sold without grills.8 different grill designs are available separately for all versions of 10� & 12� REVO HP & FA subwoofers.This will enable users to have matching grills on both REVO Coaxial In-Boat speakers & REVO Subwoofers.
Optional RGB LED Kits are available to fit under all REVO 10� & 12� subwoofer grills to enable users to have thousands of LED light display combinations.
ESPECIFICACIONES TÉCNICAS
Diameter |
12.6 inches w/grill (320.04 mm) |
|
PEAK Watts |
800 |
|
Mounting Depth |
4.92 inches (124.96 mm) |
|
Series |
REVO |
|
Sub Size |
12" |
|
Box Specs |
Optimized for Infinite Baffle (Free Air) applications or 1.3 cu ft. sealed enclosure |
|
Impedance |
4 Ohm |
|
Hole Cut Out |
11.26 inches (286.0 mm) |
|
RMS Watts |
400 |
|
Weight |
17.6 lbs (7.98 kg) |
|
Frequency Response |
20Hz to 400HZ |
|
Sensitivity |
88 db at 1watt/1 meter |
|
Cone Color |
White |
|
Application Type |
Free Air |
